JACO Compression Fitting 40 Series Male Elbow 40-5-4-P-O/40-5-4-P-PG/40-5-4-P-SG

1 Design Considerations

· Nut Style: O, ferrule nut with integral sleeve；

PG, nut with plastic gripper

SG, nut with stainless steel gripper

· PG style includes PP nut, PVDF gripper & PP sleeve;

SG style includes PP nut, stainless steel gripper & PP sleeve

· Body Material: White PP

2 Description

Part Number	Description	Body Material	Nut Style	Pressure Rating
40-5-4-P-O	5/16"OD ×1/4"MNPT	White PP	O, ferrule nut with integral sleeve	50 PSI （3.45Bar）
40-5-4-P-PG	5/16"OD ×1/4"MNPT	White PP	PG, nut with plastic gripper	220 PSI （15.17Bar）
40-5-4-P-SG	5/16"OD ×1/4"MNPT	White PP	SG, nut with stainless steel gripper	220 PSI （15.17Bar）
